4
mono balanced XLR mic and unbalanced 1/4" line and 8 stereo unbalanced
1/4" inputs (12 total)
-
Balanced
1/4" TRS and XLR Stereo Outputs
-
3
band EQ for all input channels, 7 band stereo graphic EQ for Master
Mix
-
4
balanced 1/4" TRS inserts allow independent connection of effects
devices for each mono channel
-
60
mm faders on all channels and master L/R and Effect bus mix for precise
level control
-
Switchable
20dB pad on all channel inputs
-
Tape
level control for Tape In and Record Out
|
-
Separate
Repeat control and separate effects PFL monitoring for built-in DSP
(Digital Sound Processor)
-
Headphone
output with separate volume adjust
-
PFL
control for each channel allows headphone monitoring independent of
channel volume
-
Erasable
area above all faders for notations
-
Internal
shielded AC supply with 115V(60Hz)/230V(50Hz) select switch
-
Dimensions
& Weight: 16"x17"x 3.5" (406 x 432 x 89 mm), 14.7 lbs (6.7 Kg)
|
 |
